S319 (S180)

Harness-Family: Body

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S180

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S319 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S319 Component Location

GCWD1019040

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	D55	WT	22	CAN B (+)	N/A
2	D55	WT	22	CAN B (+)	N/A
3	D55	WT	22	CAN B (+)	N/A
4	D55	WT	22	CAN B (+)	N/A
5	D55	WT	22	CAN B (+)	N/A
6	D55	WT	22	CAN B (+)	N/A
