S250 (S2860)

Harness-Family: UCI_Jpr

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S2860

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S250 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S250 Component Location

GCWD1023012

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	X440	YL	22	UCI DEVICE DETECT	N/A
2	X440	YL	22	UCI DEVICE DETECT	N/A
3	X440	YL	22	UCI DEVICE DETECT	N/A
