S221 (S1651)

Harness-Family: IP

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1651

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S221 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S221 Component Location

GCWD1019012

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	X201	GY	18	LEFT FRONT SPEAKER (+)	N/A
2	X201	GY	18	LEFT FRONT SPEAKER (+)	N/A
3	X201	GY	18	LEFT FRONT SPEAKER (+)	N/A
