S219 (S1681)

Harness-Family: IP

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1681

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S219 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S219 Component Location

GCWD1019241

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	D55	WT	20	CAN B (+)	N/A
2	D55	WT	20	CAN B (+)	N/A
3	D55	WT	20	CAN B (+)	N/A
4	D55	WT	22	CAN B (+)	N/A
5	D55	WT	22	CAN B (+)	N/A
6	D55	WT	22	CAN B (+)	N/A
8	D55	WT	22	CAN B (+)	N/A
