S215 (S1611)

Harness-Family: IP

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1611

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S215 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S215 Component Location

GCWD1019109

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	A106	LB	20	FUSED B(+)	N/A
2	A106	LB	20	FUSED B(+)	N/A
3	A106	LB	20	FUSED B(+)	N/A
4	A106	LB	20	FUSED B(+)	N/A
