S213 (S1655)

Harness-Family: IP

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1655

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S213 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S213 Component Location

GCWD1019015

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	X13	DG	16	FUSED B(+)	N/A
2	X13	DG	16	FUSED B(+)	N/A
3	X13	DG	16	FUSED B(+)	N/A
4	X13	DG	16	FUSED B(+)	N/A
