S212 (S1633)

Harness-Family: IP

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1633

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S212 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S212 Component Location

GCWD1018950

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	M27	YL	20	READING LAMPS DRIVER	N/A
2	M27	YL	22	READING LAMPS DRIVER	N/A
3	M27	YL	22	READING LAMPS DRIVER	N/A
