S200 (S1610)

Harness-Family: IP

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1610

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S200 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S200 Component Location

GCWD1019115

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	A23	RD	20	FUSED B(+)	N/A
2	A23	RD	20	FUSED B(+)	N/A
3	A23	RD	20	FUSED B(+)	N/A
4	A23	RD	20	FUSED B(+)	N/A
