S166 (S1310)

Harness-Family: HDLP_Dash

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1310

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S166 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S166 Component Location

GCWD1023675

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	A209	RD	16	FUSED B(+)	N/A
2	A209	RD	16	FUSED B(+)	N/A
3	A209	RD	16	FUSED B(+)	N/A
