S126 (S1320)

Harness-Family: HDLP_Dash

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1320

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S126 Connector End View
GCWD1006457Courtesy of CHRYSLER
Fig 2: S126 Component Location
GCWD1023769Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 F202 PK 20 IGNITION RUN/START CONTROL OUTPUT N/A
2 F202 PK 20 IGNITION RUN/START CONTROL OUTPUT N/A
3 F202 PK 20 IGNITION RUN/START CONTROL OUTPUT N/A
4 F202 PK 20 IGNITION RUN/START CONTROL OUTPUT N/A
5 F202 PK 20 IGNITION RUN/START CONTROL OUTPUT N/A
