S125 (S1394)

Harness-Family: HDLP_Dash

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1394

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S125 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S125 Component Location

GCWD1017526

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	K904	DB	20	O2 RETURN (DOWNSTREAM)	N/A
2	K904	DB	20	O2 RETURN (DOWNSTREAM)	N/A
3	K904	DB	20	O2 RETURN (DOWNSTREAM)	N/A
