S124 (S1385)

Harness-Family: HDLP_Dash

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1385

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S124 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S124 Component Location

GCWD1023577

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	D65	WT	20	CAN C (+)	N/A
2	D65	WT	22	CAN C (+)	N/A
3	D65	WT	22	CAN C (+)	N/A
4	D65	WT	22	CAN C (+)	N/A
5	D65	WT	22	CAN C (+)	N/A
6	D65	WT	22	CAN C (+)	N/A
