Radio C7 (D3843G)

Harness-Family: IP

Color: CURRY

Gender: FEMALE

Part Number: 7229-9189-70

Part Description: 1P FAKRA LC UNSEALED Female SUB-ASSY

Connector No: D3843G

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Radio C7 Connector End View

Courtesy of CHRYSLER

Fig 2: Radio C7 Component Location

Courtesy of CHRYSLER
