Radio C4 (D3843D)

Harness-Family: IP

Color: SIGNAL WHITE

Gender: FEMALE

Part Number: 776683-2

Part Description: RG-59, 90 DEGREE, FAKRA, SMB

Connector No: D3843D

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Radio C4 Connector End View

GCWD1025403

Courtesy of CHRYSLER

Fig 2: Radio C4 Component Location

GCWD1018300

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
D1	D5	BK	06	ANTENNA SIGNAL	N/A
D1	D931	BK	999	ANTENNA SHIELD	N/A
