Radio C1 (D3843A)

Harness-Family: IP

Color: GRAY

Gender: FEMALE

Part Number: 638207-6

Part Description: INSULATOR

Connector No: D3843A

Option: Standard

Repair Kit Part Number: 05135638AA

Cavity Count: 10

Fig 1: Radio C1 Connector End View

GCWD1024704

Courtesy of CHRYSLER

Fig 2: Radio C1 Component Location

GCWD1018295

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
A1	X703	DG	20	LEFT AUDIO OUTPUT	N/A
A1	X722	LB	20	MICROPHONE 2 IN (+)	N/A
A10	X445	DB	22	UCI USB DATA (-)	NAVIGATION
A2	X704	DG	20	RIGHT AUDIO OUTPUT	N/A
A2	X712	DG	20	MICROPHONE 1 IN (+)	N/A
A3	X439	BR	22	UCI ID	NAVIGATION
A4	X793	DG	20	MICROPHONE FEED	N/A
A6	X795	DG	20	COMMON AUDIO OUTPUT	N/A
A7	X792	GY	20	MICROPHONE IN (-)	N/A
A8	X835	OR	20	SENSOR GROUND	N/A
A9	X444	GY	22	UCI USB DATA (+)	NAVIGATION
