Motor-Adjustable Pedals (D3001)

Harness-Family: Body

Color: NATURAL

Gender: FEMALE

Part Number: 7123-8365

Part Description: SDL TYPE INSULATOR

Connector No: D3001

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 6

Fig 1: Motor-Adjustable Pedals Connector End View

GCWD1016797

Courtesy of CHRYSLER

Fig 2: Motor-Adjustable Pedals Component Location

GCWD1021749

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	P206	LG	16	ADJUSTABLE PEDALS MOTOR REARWARD	N/A
2	P205	LG	16	ADJUSTABLE PEDALS MOTOR FORWARD	N/A
