Lighter-Cigar (D6601)

Harness-Family: IP

Color: GRAY

Gender: FEMALE

Part Number: 1478-5000

Part Description: CIGAR LIGHTER CONNECTOR ASSEMBLY

Connector No: D6601

Option: Standard

Repair Kit Part Number: 05019916AB

Cavity Count: 3

Fig 1: Lighter-Cigar Connector End View

Courtesy of CHRYSLER

Fig 2: Lighter-Cigar Component Location

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	A205	RD	16	FUSED B(+)	N/A
3	Z910	BK	16	GROUND	N/A
