Latch-Door-Passenger (D6615)

Harness-Family: Door_Pass

Color: BLACK

Gender: FEMALE

Part Number: 7283-7040-30

Part Description: 090 II 4POLE SEALED INSL

Connector No: D6615

Option: Standard

Repair Kit Part Number: 05161916AA

Cavity Count: 4

Fig 1: Latch-Door-Passenger Connector End View

GCWD1025465

Courtesy of CHRYSLER

Fig 2: Latch-Door-Passenger Component Location

GCWD1018820

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	G74	VT	22	PASSENGER DOOR AJAR SWITCH SENSE	N/A
2	Z911	BK	20	GROUND	N/A
3	P303	TN	22	PASSENGER DOOR UNLOCK DRIVER	N/A
4	P392	LG	22	DOOR LOCK DRIVER RIGHT DOORS	N/A
