Lamp-Glove Box (D4536)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 1443

Part Description: INS

Connector No: D4536

Option: Standard

Repair Kit Part Number: 05135636AA

Cavity Count: 2

Fig 1: Lamp-Glove Box Connector End View

GCWD1016785

Courtesy of CHRYSLER

Fig 2: Lamp-Glove Box Component Location

GCWD1023552

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	Z909	BK	22	GROUND	N/A
2	M27	YL	22	READING LAMPS DRIVER	N/A
