Lamp-FOOTWELL-Right Rear (D4600)

Harness-Family: Door_Right_Rear

Color: NATURAL

Gender: FEMALE

Part Number: 7283-5845

Part Description: 040-III CONNECTOR HOUSING SUB ASSEMBLY

Connector No: D4600

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Lamp-Footwell-Right Rear Connector End View

Courtesy of CHRYSLER

Fig 2: Lamp-Footwell-Right Rear Component Location

Courtesy of CHRYSLER
