Lamp-Center High Mounted Stop C2 (D4509B)

Harness-Family: Body

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 7283-6443-40

Part Description: 2P KAIZEN YESC 1.5MM Female SUB ASSEMBLY

Connector No: D4509B

Option: Standard

Repair Kit Part Number: 68065023AA

Cavity Count: 2

Fig 1: Lamp-Center High Mounted Stop C2 Connector End View

Courtesy of CHRYSLER

Fig 2: Lamp-Center High Mounted Stop C2 Component Location

Courtesy of CHRYSLER
