G304 (G31)

Harness-Family: HDLP_Dash

Color: NA

Gender: FEMALE

Part Number: 7009-1351-02

Part Description: EYELET TERMINAL (TIN)

Connector No: G31

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: G304 Connector End View

GCWD1025456

Courtesy of CHRYSLER

Fig 2: G304 Component Location

GCWD1021018

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	Z931	BK	10	GROUND	N/A
