G303 (G15)

Harness-Family: Battery_Negative

Color: NA

Gender: FEMALE

Part Number: 7009-1968-02

Part Description: TERMINAL

Connector No: G15

Option: 3.5L

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: G303 Connector End View

GCWD1016824

Courtesy of CHRYSLER

Fig 2: G303 Component Location

GCWD1023240

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	Z915	BK	02F	GROUND	N/A
