G200A (G13)

Harness-Family: IP

Color: NA

Gender: FEMALE

Part Number: 04604460

Part Description: Not Available

Connector No: G13

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: G200a Connector End View

GCWD1006354

Courtesy of CHRYSLER

Fig 2: G200a Component Location

GCWD1021690

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	Z939	BK	18	GROUND	N/A
