G104 (G16)

Harness-Family: Engine

Color: NA

Gender: FEMALE

Part Number: 56038431

Part Description: INTERLOCKING EYELET (LEFT)

Connector No: G16

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: G104 Connector End View

GCWD1013371

Courtesy of CHRYSLER

Fig 2: G104 Component Location

GCWD1017910

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	Z906	BK	14	GROUND	N/A
1	Z917	BK	06	GROUND	N/A
