Coil-Ignition 8 (D5211)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 184311-1

Part Description: SEALED SENSOR CONNECTOR

Connector No: D5211

Option: Standard

Repair Kit Part Number: 05019952AA

Cavity Count: 3

Fig 1: Coil-Ignition 8 Connector End View

GCWD1006558

Courtesy of CHRYSLER

Fig 2: Coil-Ignition 8 Component Location

GCWD1018584

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	K98	DB	16	COIL CONTROL 8	N/A
2	F343	BR	16	FUSED ASD RELAY OUTPUT	N/A
