Coil-Ignition 7 (D5210)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 184311-1

Part Description: SEALED SENSOR CONNECTOR

Connector No: D5210

Option: Standard

Repair Kit Part Number: 05019952AA

Cavity Count: 3

Fig 1: Coil-Ignition 7 Connector End View

GCWD1006558

Courtesy of CHRYSLER

Fig 2: Coil-Ignition 7 Component Location

GCWD1018585

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	K97	DB	16	COIL CONTROL 7	N/A
2	F343	BR	16	FUSED ASD RELAY OUTPUT	N/A
