Cluster C1 (D3809A)

Harness-Family: IP

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 917992-6

Part Description: INSULATOR

Connector No: D3809A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 26

Fig 1: Cluster C1 Connector End View

GCWD1016854

Courtesy of CHRYSLER

Fig 2: Cluster C1 Component Location

GCWD1020271

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
A10	G77	VT	22	LEFT REAR DOOR AJAR SWITCH SENSE	N/A
A11	P1	TN	20	DRIVER DOOR UNLOCK DRIVER	N/A
A12	P393	LG	20	DOOR LOCK DRIVER LEFT DOORS	N/A
A13	P392	LG	20	DOOR LOCK DRIVER RIGHT DOORS	N/A
A14	Z910	BK	16	GROUND	N/A
A15	Z910	BK	16	GROUND	N/A
A16	D55	WT	20	CAN B (+)	N/A
A17	D54	WT	20	CAN B (-)	N/A
A18	B25	GY	22	PARK BRAKE SWITCH SENSE	N/A
A2	Z910	BK	18	GROUND	N/A
A20	B27	DG	22	TRACTION CONTROL SWITCH SENSE	N/A
A22	G25	VT	22	DECKLID/LIFTGATE RELEASE SWITCH SENSE	N/A
A23	G78	VT	22	DECKLID/LIFTGATE AJAR SWITCH SENSE	N/A
A24	A110	OR	16	FUSED B(+)	N/A
A25	A110	OR	16	FUSED B(+)	N/A
A26	P303	TN	20	PASSENGER DOOR UNLOCK DRIVER	N/A
A3	L307	WT	22	HEADLAMP SWITCH MUX	N/A
A4	E2	OR	22	PANEL LAMPS DRIVER	N/A
A5	G161	VT	22	LEFT DOOR LOCK SWITCH MUX	N/A
A6	G160	VT	22	PASSENGER DOOR LOCK SWITCH MUX	N/A
A9	G76	VT	22	RIGHT REAR DOOR AJAR SWITCH SENSE	N/A
