Antenna-Passive Entry 3 (D3103)

Harness-Family: IP

Color: BLUE

Gender: FEMALE

Part Number: 3-929080-1

Part Description: 2P MQS SOCKET HOUSING

Connector No: D3103

Option: Standard

Repair Kit Part Number: 68087929AA

Cavity Count: 2

Fig 1: Antenna-Passive Entry 3 Connector End View

GCWD1025405

Courtesy of CHRYSLER

Fig 2: Antenna-Passive Entry 3 Component Location

GCWD1023951

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	D924	GY	22	PASSIVE ENTRY ANTENNA 3 SIGNAL	N/A
2	D925	GY	22	PASSIVE ENTRY ANTENNA 3 RETURN	N/A
