Speaker-Left Rear (D5918)

Harness-Family: Body

Color: NATURAL

Gender: FEMALE

Part Number: 174921-1

Part Description: 070 SERIES MULTILOCK CONNECTOR PLUG HSG

Connector No: D5918

Option: Standard

Repair Kit Part Number: 68040489AA

Cavity Count: 3

Fig 1: Speaker-Left Rear Connector End View
GCWD1006318Courtesy of CHRYSLER
Fig 2: Speaker-Left Rear Component Location
GCWD1022292Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 X393 DG 18 LEFT REAR SPEAKER (-) N/A
3 X303 DG 18 LEFT REAR SPEAKER (+) N/A
