Motor-Steering Tilt (D3051)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 772-717-501

Part Description: SLK 2.8 CONNECTOR

Connector No: D3051

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 4

Fig 1: Motor-Steering Tilt Connector End View

GCWD1025394

Courtesy of CHRYSLER

Fig 2: Motor-Steering Tilt Component Location

GCWD1024207

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	P953	DG	16	STEERING MOTOR COMMON	N/A
2	P153	TN	16	TILT STEERING MOTOR UP/DOWN DRIVER	N/A
3	P151	TN	20	TILT STEERING UP/DOWN POSITION SENSE	N/A
4	G914	VT	20	SENSOR GROUND	N/A
