Airbag-Side Curtain-Right (D3084)

Harness-Family: Body

Color: YELLOW

Gender: FEMALE

Part Number: 54550266

Part Description: CONNECTOR ASSEMBLY (ABX-3 AIRBAG)

Connector No: D3084

Option: Standard

Repair Kit Part Number: 68053130AA

Cavity Count: 2

Fig 1: Airbag-Side Curtain-Right Connector End View

Courtesy of CHRYSLER

Fig 2: Airbag-Side Curtain-Right Component Location

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	R4	OR	20	RIGHT CURTAIN SQUIB 1 LINE 1	N/A
2	R2	WT	20	RIGHT CURTAIN SQUIB 1 LINE 2	N/A
