Diagnostic Test

1) INSPECT THE RIGHT TURN SIGNAL INDICATOR LAMP
Turn the ignition off.

Remove the Right Turn Signal Indicator Lamp from the Instrument Cluster and inspect the lamp for an open filament.

Is the lamp filament open?

Yes
1. Replace the Right Turn Signal Indicator Lamp. Refer to INSTRUMENT CLUSTER BULB REPLACEMENT PROCEDURE .
2. Perform *BODY VERIFICATION TEST .
No
1. Go to step 2).
2) MEASURE RIGHT TURN SIGNAL INDICATOR CIRCUIT RESISTANCE

Fig 1: Measuring Resistance Of Right Turn Signal Indicator Circuit
Courtesy of CHRYSLER LLC

With the ignition off.

Disconnect the Remote Keyless Entry Relay.

Disconnect the Instrument Cluster C1 harness connector.

NOTE: Check connectors - Clean/repair as necessary.

Measure the resistance of the Right Turn Signal Indicator circuit from the RKE Relay harness connector cavity 5 to the Instrument Cluster C1 harness connector cavity A10.

Is the resistance below 5.0 ohms?

Yes
1. Replace the Instrument Cluster. Refer to REMOVAL .
2. Perform *BODY VERIFICATION TEST .
No
1. Repair the Right Turn Signal Indicator Driver circuit for an open.
2. Perform *BODY VERIFICATION TEST .
