DTC 1283-00: Right Power Window Motor Circuit Failure: Notes

Fig 1: Right Front Power Window Circuit Schematic

Courtesy of CHRYSLER LLC

POSSIBLE CAUSES
LEFT FRONT POWER WINDOW MOTOR
LEFT FRONT POWER WINDOW DRIVER CIRCUIT
BODY CONTROL MODULE

For a complete Body Control Module Circuit Diagram, see SCHEMATICS AND DIAGRAMS .
