Removal - LHD

Fig 1: Pedal Position Sensor
GC0021653Courtesy of DAIMLERCHRYSLER CORP.
  1. Remove the air cleaner cover.
  2. Disconnect the negative battery cable.
  3. Remove the mounting bolt.
  4. Remove assembly from the mounting bracket.
  5. Open the APPS module cover and disconnect the cable from the cam and module.
