2.4L DOHC: Description

Fig 1: Engine Identification

Courtesy of DAIMLERCHRYSLER CORP.

The 2.4 Liter (148 cu. in.) in-line four cylinder engine is a double over head camshaft with hydraulic lash adjusters and four valve per cylinder design. The engine is free-wheeling; meaning it has provisions for piston-to-valve clearance. However valve-to-valve interference can occur, if camshafts are rotated independently.

The cylinders are numbered from front of the engine to the rear. The firing order is 1-3-4-2.

The engine identification number (1) is located on the rear of the cylinder block. See Fig 1.
