Rings-Piston: Removal

Fig 1: Piston Rings-Removing and Installing
GC0021232Courtesy of DAIMLERCHRYSLER CORP.
  1. Using a suitable ring expander, remove upper and intermediate piston rings. See Fig 1.
  2. Remove the upper oil ring side rail, lower oil ring side rail and then oil ring expander from piston.
  3. Clean ring grooves of any carbon deposits.
