Liftgate Weatherstrip: Removal

Fig 1: Door Outer Belt Weatherstrip
GC0022605Courtesy of DAIMLERCHRYSLER CORP.
1 - LIFTGATE OPENING
2 - LIFTGATE OPENING WEATHERSTRIP
  1. Open liftgate.
  2. Remove weatherstrip (2), pull outward on the weatherstrip.
  3. Remove outer belt weatherstrip from vehicle.
