Center High Mounted Stop Lamp: Installation

  1. Install bulb(s) into the lamp housing. See Figure.
  2. Snap the CHMSL lens onto the lamp housing.
  3. Test operation of lamps.
  4. Install liftgate CHMSL cover.
  5. Close liftgate.
