Radio Noise Suppression Capacitor

  1. Disconnect and isolate the battery negative cable.
  2. Disconnect electrical harness connector from capacitor. See Fig 1.
    Fig 1: RADIO NOISE CAPACITOR - TYPICAL
    GC0022867Courtesy of DAIMLERCHRYSLER CORP.
    1 - RADIO NOISE CAPACITOR
    2 - EXHAUST MANIFOLD
  3. Remove bolt from capacitor and remove capacitor.
