Center Console Closeout Panel: Removal

  1. Remove attaching screw. See Fig 1 and/or Fig 2
  2. Remove center console closeout panel.
Fig 1: LEFT CONSOLE CLOSEOUT PANEL
GC0001079Courtesy of DAIMLERCHRYSLER CORP.
1 - ATTACHING SCREW
2 - LEFT CONSOLE CLOSEOUT PANEL
Fig 2: RIGHT CONSOLE CLOSEOUT PANEL
GC0001080Courtesy of DAIMLERCHRYSLER CORP.
1 - RIGHT CONSOLE CLOSEOUT PANEL
2 - ATTACHING SCREW
