Symptom: NO ODOMETER MESSAGE: Testing

Fig 1: Testing No Odometer Message (1 Of 2)

G02696475

Courtesy of DAIMLERCHRYSLER CORP.

Fig 2: Testing No Odometer Message (2 Of 2)

G02696476

Courtesy of DAIMLERCHRYSLER CORP.
