Left Lower Instrument Silencer Panel: Installation

WARNING: This page is about a different car, the 2005 Dodge Stratus and 2005 Chrysler Sebring. However, it is still accessible from the selected car via links, so may be relevant.
  1. Position silencer panel over HVAC stud. See Figure.
  2. Install stamp nut and install push in fastener.
  3. Connect deck lid release wire connector.
  4. Position the left lower instrument panel trim over the retaining slots and firmly push into place.
  5. Install five screws attaching left lower instrument panel trim.
  6. Connect power mirror switch wire connector.
  7. Install instrument panel bezel.
  8. Install end cap.
