Door Glass: Removal
WARNING: This page is about a different car, the 2005 Dodge Stratus and 2005 Chrysler Sebring. However, it is still accessible from the selected car via links, so may be relevant.
- Remove door trim panel and inner belt weatherstrip.
- Connect power window switch or install crank and lower window to 50 mm (2 in.) from bottom of travel.
- Loosen bolts holding rear lower run channel to inner door panel. See Fig 1.
- Separate rear run channel from door.
- Loosen screws holding regulator roller channel to glass.
- Slide roller channel rearward to allow screw heads to pass through key hole slots in channel.
- Separate glass from roller channel.
- Lift glass upward and out of the opening at top of door.
| 1 - REAR DOOR GLASS |
| 2 - LOWER RUN CHANNEL |
| 3 - REAR DOOR |
| 4 - LIFT CHANNEL |
