Rear Bumper Reinforcement: Removal

WARNING: This page is about a different car, the 2005 Dodge Stratus and 2005 Chrysler Sebring. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove rear fascia.
  2. Support bumper reinforcement on a suitable lifting device.
  3. Mark position of nuts on frame rail to aid in installation.
  4. Remove nuts attaching rear bumper reinforcement to frame rail. See Fig 1.
  5. Remove bumper reinforcement from vehicle.
Fig 1: Rear Bumper Reinforcement
GC0031262Courtesy of DAIMLERCHRYSLER CORP.
1 - FRAME RAIL
2 - FRONT BUMPER REINFORCEMENT
