Left Mount: Installation

WARNING: This page is about a different car, the 2005 Dodge Stratus and 2005 Chrysler Sebring. However, it is still accessible from the selected car via links, so may be relevant.
  1. Position mount to frame rail. Install mount to frame rail fasteners (B). See Figure. Torque fasteners to 33 N.m (24 ft. lbs.).
  2. Raise transmission into position with floor jack.
  3. Install three vertical bolts from mount to transmission bracket (A). See Figure. Torque fasteners to 61 N.m (45 ft. lbs.).
  4. Remove floor jack and wooden block.
  5. Install speed control servo to left shock tower. Torque fasteners to 6.7 N.m (60 in. lbs.)
  6. Install throttle body air inlet hose and air cleaner housing assembly.
  7. Connect negative battery cable.
