<< B >> Oil Pan, Upper Removal

WARNING: This page is about a different car, the 2005 Dodge Stratus and 2005 Chrysler Sebring. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the long bolts "A" shown in the illustration first.
  2. Remove all other bolts.
    CAUTION: Do not use a scraper or special tool to remove the oil pan.
  3. Remove the oil pan.
    Fig 1: Removing Long Bolts "A"
    G04538457Courtesy of DAIMLERCHRYSLER CORPORATION
  4. Screw M10 bolts into the two bolt holes in the oil pan to break the joint and remove the oil pan.
    Fig 2: Removing Oil Pan
    G04538458Courtesy of DAIMLERCHRYSLER CORPORATION
