>> A << Valve Stem Seal Installation

WARNING: This page is about a different car, the 2005 Dodge Stratus and 2005 Chrysler Sebring. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the valve spring seat.
    CAUTION: The valve stem seal for the exhaust side is different than the intake side. They are identified by their respective rubber colors. When installing, do not confuse them.
    Fig 1: Installing Valve Spring Seat
    G04538438Courtesy of DAIMLERCHRYSLER CORPORATION
    CAUTION: The special tool must be used to install the valve stem seal. Improper installation could result in oil leaking past the valve guide.
  2. Using special tool MD998774, install a new stem seal to the valve guide.
    Fig 2: Installing Stem Seal To Valve Guide Using Special Tool MD998774
    G04538439Courtesy of DAIMLERCHRYSLER CORPORATION
