>> K << Oil Pan Installation

WARNING: This page is about a different car, the 2005 Dodge Stratus and 2005 Chrysler Sebring. However, it is still accessible from the selected car via links, so may be relevant.

Clean both gasket surfaces of oil pan and cylinder block.
Apply a 4 mm (0.15 inch) diameter bead of sealant (MITSUBISHI Genuine Part number MD970389 or equivalent) to the flange of the oil pan.
Apply sealant as indicated by the broken line in the illustration; the grooves must be traced and the bolt holes must be surrounded with a bead of sealant.
Install the oil pump case assembly to the front side of the cylinder block.
NOTE: Be sure to install the oil pan quickly while the sealant is wet (within 15 minutes).

Fig 1: Applying Sealant To Flange Of Oil Pan
Courtesy of DAIMLERCHRYSLER CORPORATION
Fit an 8 mm (0.30 inch) long bolt in each of the two holes identified by the letter "S" in the illustration and a 10 mm (0.39 inch) long bolt in each of the remaining 17 holes. Tighten all bolts to the specified torque.
Tightening torque: 9.0 +/- 3.0 N.m (80 +/- 26 in-lb)

NOTE: After installation, keep the sealed area away from the oil for approximately one hour.

Fig 2: Identifying Long Bolt Holes Of Oil Pan
Courtesy of DAIMLERCHRYSLER CORPORATION
