Replacement Of Headlight Bulb < Low Beam >

WARNING: This page is about a different car, the 2005 Dodge Stratus and 2005 Chrysler Sebring. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the horn (LH side only).
  2. Disconnect the connector.
    Fig 1: Removing Horn (LH Side Only)
    G04539491Courtesy of DAIMLERCHRYSLER CORPORATION
    CAUTION: Do not touch the surface of the bulb with hands or dirty gloves as the bulb may pop after a short time. If the surface does become dirty, clean it with alcohol or thinner, and let it dry thoroughly before installing.
  3. Remove the headlight bulb
  4. Install the sealing cover securely after the bulb replacement, or the lens will be out of focus, or water will get inside the light unit.
    Fig 2: Installing Sealing Cover Securely After Bulb Replacement (1 Of 2)
    G04539492Courtesy of DAIMLERCHRYSLER CORPORATION
